Liquid Phase

Carbon Steel Drums

Liquid phase carbon steel drums are one of the most economical and versatile carbon filtration systems.  Ideal for a variety of commercial projects, limited applications, temporary sites, and secondary site clean-ups, these systems are easy to install, change-out, and remove.  The drum systems are designed for projects requiring low flow rates, but they can be placed in a series to achieve greater gallons per minute.

Applications:

Drum Volume:   55 gallon



Note:  Additional drum sizes available upon request.  Actual configurations may vary.



Flow Rate:  10 gpm per drum (Additional flow rates can be achieved by adding drums in a series).



Drum Material:  16-gauge steel body with removable lids and a double epoxy phenolic coating over the entire inner surface.  1 ½ “ or 2” internals.



Dimensions:  23  7/16”  x  35  1/16 “



Carbon:  180 lbs.  of  8  x  30 mesh carbon



Design Pressure:  5 psi MAX



Liquid Phase Drum Specifications:

Drain

Influent

Effluent
